55-inch Ultra-Narrow Bezel Video Walls
Create a multi-screen display with a 0.88mm combined panel bezel and 500cd/m² IPS panels. We help you compare wall layouts, viewing distances and service access before selecting the screens.
Product overview
Commercial grade.
Locally supported.
Site survey, mounting, commissioning and handover by our own team.
Advice and aftercare across Northern Ireland and the Republic of Ireland.
Specifications at a glance
| Panel size | 55 inches |
|---|---|
| Combined panel bezel | TL55S2: 0.44 mm per edge; 0.88 mm combined |
| Brightness | 500 cd/m² IPS panel |
| Signal handling | HDMI daisy chain accepts a 4K source |
| Orientation | Landscape or portrait |
| Duty rating | 24/7 commercial operation |
| Warranty | 3-year standard commercial warranty |
Choosing this range
For a tiled LCD wall in reception, retail or a control space. Plan the array, viewing distance, source resolution and maintenance access before choosing mounts.
Compare related options
- 55-inch LCD Video Wall Displays: Compare the alternative bezel width to judge how visible the joins will be.
- Large Format 4K Commercial Displays: Compare a single large display when avoiding panel joins is more important than building a larger array.
Models and sizes
Choose the
right format.
55” 49”
TECHNICAL LIBRARY
Specification downloads
55" TL55S2 LCD Video Wall - Spec SheetSpec sheet49" TL49H9 - Model Reference SheetSpec sheet55" TL55H9 - Model Reference SheetSpec sheet
Need a user manual, installation guide or technical drawing? Ask our team and we will supply the correct document for the confirmed model.
The current 55-inch TL55S2 sheet covers the 0.88mm combined bezel range. TL49H9 and TL55H9 files are separate model references; their specifications must not be applied to TL55S2.
Before we specify a screen
A system planned
around your site.
A product page is a useful starting point, but the correct display depends on where it will be used and what it needs to achieve. Digi Sign checks the installation environment before confirming a model, so the screen, mounting method and content platform work together.
We assess indoor or outdoor use, ambient light, viewing distance and the direction customers approach from. This helps us confirm brightness, screen size and orientation.
We discuss daily operating hours, expected content, network access and whether staff need remote updates across one location or several sites.
Wall structure, cable routes, power, ventilation and service access are considered before installation. Our team can survey, install, commission and hand over the complete system.
Where suitable, ScreenZeno provides cloud content management. Zoe can help prepare on-brand layouts, while Raphael and Corey support the technical delivery and aftercare.
Common questions
What should I know
before ordering?
Will an LCD video wall have visible joins?
Yes. The listed TL55S2 has a 0.44 mm bezel per edge, giving a 0.88 mm combined join between panels. If the design needs an image without LCD panel joins, compare a direct-view LED wall.
Does accepting a 4K source mean each panel is 4K?
No. The HDMI daisy chain can accept a 4K source; that is a signal-handling specification. The final image depends on the selected panels, wall layout and processing, which we confirm together.
How is the wall layout specified?
We start with the finished width and height, viewing distance and content. The 55-inch panels can be installed in landscape or portrait. Mounting alignment, service access, power and signal distribution form part of the installation plan.
Should I choose an LCD wall or direct-view LED?
LCD can suit a regular indoor grid where close viewing matters and narrow panel joins are acceptable. Direct-view LED can suit a seamless image or custom shape. Compare both against the same dimensions, content and installed scope.
Get a complete proposal
Screen, software
and installation.
We will confirm the correct model, mounting method, ScreenZeno setup and installation cost for your location.
