All productsTouch Screens
PCAP Commercial Touch Screen Monitors
Add touch interaction to a wall display, fitted kiosk or Windows-based installation with a PCAP monitor. We help you check the enclosure, input connections and software requirements before choosing a configuration.
Product overview
Commercial grade.
Locally supported.
Site survey, mounting, commissioning and handover by our own team.
Advice and aftercare across Northern Ireland and the Republic of Ireland.
Specifications at a glance
| Screen sizes | 22, 32, 43, 50 and 55 inches |
|---|---|
| Resolution by size | 22/32-inch: 1920 × 1080; 43/50/55-inch: 3840 × 2160 |
| Brightness | 500 cd/m² |
| Touch | 10-point projected capacitive (PCAP) |
| Computer options | External source or optional Windows OPS PC |
| Installation | Landscape or portrait; wall, stand or open-frame integration |
| Operating duty | 24/7 commercial use |
| Warranty | 3-year standard commercial warranty |
Choosing this range
For installations where the software runs on a separate computer, or the screen needs to fit into a custom kiosk or cabinet. Choose the optional OPS PC only when an integrated computer is required.
Compare related options
- Android PCAP Interactive Touch Screens: For a screen with an Android player built in.
- 4K Interactive Displays for Schools & Offices: For large shared annotation and wireless meeting-room presentations.
Models and sizes
Choose the
right format.
22” 32” 43” 50” 55”
TECHNICAL LIBRARY
Specification downloads
22" PCAP Touch Screen Monitors - Spec SheetSpec sheet32" PCAP Touch Screen Monitors - Spec SheetSpec sheet43" PCAP Touch Screen Monitors - Spec SheetSpec sheet50" PCAP Touch Screen Monitors - Spec SheetSpec sheet55" PCAP Touch Screen Monitors - Spec SheetSpec sheetEssential OPS Slot-in PC Intel® i5 - Spec SheetSpec sheetPremium OPS Slot-in PC Intel® Core™ i5 - Spec SheetSpec sheet
Need a user manual, installation guide or technical drawing? Ask our team and we will supply the correct document for the confirmed model.
The Essential ES1 and Premium P6 OPS accessory sheets specify five years when purchased with an Interactive Touch Display, otherwise three years. This accessory condition does not extend the standard three-year warranty of the PCAP monitor itself.
Before we specify a screen
A system planned
around your site.
A product page is a useful starting point, but the correct display depends on where it will be used and what it needs to achieve. Digi Sign checks the installation environment before confirming a model, so the screen, mounting method and content platform work together.
We assess indoor or outdoor use, ambient light, viewing distance and the direction customers approach from. This helps us confirm brightness, screen size and orientation.
We discuss daily operating hours, expected content, network access and whether staff need remote updates across one location or several sites.
Wall structure, cable routes, power, ventilation and service access are considered before installation. Our team can survey, install, commission and hand over the complete system.
Where suitable, ScreenZeno provides cloud content management. Zoe can help prepare on-brand layouts, while Raphael and Corey support the technical delivery and aftercare.
Common questions
What should I know
before ordering?
Can I see this type of display before buying?
Showroom visits are available by appointment in Moneymore. We can demonstrate relevant commercial display formats and discuss the best option for your site.
Does Digi Sign cover both Northern Ireland and the Republic of Ireland?
Yes. We design, supply, install and support commercial display projects throughout Northern Ireland and the Republic of Ireland, with UK-wide support available for suitable projects.
Can the screen be supplied with content management?
Yes. Compatible installations can include ScreenZeno for remote scheduling and updates. We will confirm compatibility and the required player or network setup in your proposal.
Are the specification downloads hosted by Digi Sign?
Yes. Download the model specification sheets below, or ask us to explain the differences and recommend a suitable size for your installation.
Get a complete proposal
Screen, software
and installation.
We will confirm the correct model, mounting method, ScreenZeno setup and installation cost for your location.
Request a quotation
